| Model No. | Q40052R | Q55052R | Q75052R | Q90052R |
| Rated Power | 400W | 550W | 750W | 900W |
| Vol&Fre | 230V/50Hz | 230V/50Hz | 230V/50Hz | 230V/50Hz |
| Max.pump height | 6.5m | 7.5m | 8.5m | 9.0m |
| Max.pump rate | 7500l/h | 8500l/h | 11000l/h | 13000l/h |
| Max.submersible depth | 7m | 7m | 7m | 7m |
| Max.grain size | 5mm | 5mm | 5mm | 5mm |
| Max.pressure | 0.65bar | 0.75bar | 0.85bar | 0.9bar |
| Dia of connecting pipe | 1"G1"1-1/4"G1-1/4" | 1"G1"1-1/4"G1-1/4" | 1"G1"1-1/4"G1-1/4" | 1"G1"1-1/4"G1-1/4" |
| Cable specification | HO5RN-F3G0.75mm² | HO5RN-F3G1.0mm² | HO5RN-F3G1.0mm² | HO7RN-F3G1.0mm² |
| Length of cable | 10m | 10m | 10m | 10m |
| Lowest pump starting level | 35mm | 35mm | 35mm | 35mm |
| Lowest pump sucking level | 11mm | 11mm | 11mm | 11mm |
| Max.medium temperature | 35℃ | 35℃ | 35℃ | 35℃ |
| Qty in carton box size | 4pcs | 4pcs | 4pcs | 4pcs |
| Master carton box size | 46x34x33cm | 46x34x33cm | 46x34x33cm | 46x38x33cm |
| Master carton box gross weight | 19.9kg | 22.8kg | 23.6kg | 26.7kg |
| Qty/20’GP | 2172pcs | 2172pcs | 2172pcs | 2172pcs |
